3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots

Product Description
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots manufacture

Main features of Automatic dispenser equipment

1.Operation with handheld LCD panel teach box,which is easy to program and learn. 2.Functions of drawing points,lines,surfaces,arc,circle and consecutive interpolation of irregular curves to realize any 3D non planar trajectory path. 3.Excellent teaching function to support array,graphical browsing,three dimensional elliptic,common graphical library inserting,group editing and so on. 4.MINISD file storage with high speed and 2G capacity can store 999 dispensing process documents. 5.The size of glue,speed of glue spread,dispensing time,time of halting dispensing can be set by parameters. 6.With Second special dispensing controller,glue outflow is quite stable without leaking and dripping. 7.The function of automatic gel prevention can effectively prevent glue curing from jamming needle head. 8.Powerful PC compatibility with the Logoshop software can import mainstream design software(such as Auto CAD,Coral Draw,etc.) to generate a variative of file formats(such as,.NC,.AI,.DXF,.JPG,.BMP,scanner,etc.) 9.It is applied to fluid dispensing, such as, UV glue, AB glue,COB(black glue), white glue, EMI conductive glue, silicon, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, screw fixative and so on.
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots factory
Specification
Model
MD-DD-T3311
MD-DD-T4411
MD-DD-T5511
MD-DD-T53311
MD-DD-T54411




Stroke X
300mm
400mm
500mm
500mm
500mm




Stroke Y1
300mm
400mm
500mm
300mm
400mm




Stroke Y2
no
no
no
300mm
400mm




Stroke Z
100mm
100mm
100mm
100mm
100mm




Glue capacity
300ml-330ml




Driving method
stepping motor / servo motor




Applicable viscosity value
≤10000cps




Gluing time
0.8-5 S / time




Glue amount
0.01-5 ml /time




Spit frequency
1-250 (times / minute)




Moving method
point to point/linear/circle




Programing interface
teaching box/PC




Repeat accuracy
+-0.02mm




Speed
0.1-800mm/sec




Available Graph
line/circle/arc/continuous line/3D irregularity line




Program storage
100groups/1000points per group




Port
RS232




Power
AC110V- 240V/50Hz




Air
0.5Mpa




Distinguishing Feature

It runs alternately with a double platform, saving the time for the product to be taken and put. It is independent of the mold. It is an aluminum profile casting structure with beautiful appearance. It has a hand-held teaching programmer, which is fast and easy to program. Its glue speed and glue amount can be set separately. It is controlled by a high precision stepping motor, and the trail is accurate. It can finish any shape point glue, such as space point, line, arc, etc. It contains a variety of glue needles, syringes, glue valves and controllers to meet different requirements.

Applicable Industry

Plastic labels, zipper heads, key chains, bookmarks, key cases, U disk shells, MP3 shells, mobile phone lanyards, mobile phone ornaments, mobile phone holders, mobile phone wipes, wrist straps, silicone bracelets, silicone necklaces, PVC car mats, Refrigerator stickers, mouse pads, coasters, glasses silicone covers, etc., suitable for clothing, shoes and hats, services, electronic appliances, toys, gifts, home, etc.
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots supplier
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots supplier
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots factory
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots manufacture
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots manufacture
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots factory
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots factory
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots factory
3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots details
FAQ
1. who are we?
We are based in Guangdong, China, start from 2014,sell to North America(20.00%),Western Europe(20.00%),South Asia(20.00%),Southeast Asia(15.00%),Mid East(10.00%),South America(5.00%),Eastern Asia(5.00%),Northern Europe(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Soldering machine,Spot welding machine,Plasma cleaning machine,Glue dispenser,Screw machine

4. why should you buy from us not from other suppliers?
with ultra professional service and skill to provide high performance but competitive price goods, the customer's success is our own success.

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FCA,CPT;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,PayPal,Cash;
Language Spoken:English,Chinese

Minder-Hightech 3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots will be the appropriate service for your whole automated epoxy glue dispensing demands. This progressed Silicone Epoxy Resin Adhesive Dispenser robot is made up of advanced innovation that guarantees dispensing and precise accurate of. With Minder-Hightech 3 Axis Dispensing Robot, you can quote farewell into the tiresome and copied job of adhesive dispensing.



The Minder-Hightech 3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots is a greater degree and flexible robotic device towards be used in a great deal of requests, consisting of electronic devices, automobile, clinical gadgets, and lots of various other business.
The robot is efficient in dispensing glues in a wide range of, dimensions, and practices with unrivaled repeatability and accuracy.


This 3-axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots’ functions three-axis movement that guarantees complete protection the task location, allowing extensive adhesive request. The robot typically geared up with a digital high-resolution video cam which enables drivers towards screen the adhesive dispensing procedure with simplicity. This specific include that driver can change any type of errors which might happen throughout the dispensing treatment.



The Minder-Hightech 3 axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots is easy and easy to use towards utilize.
The gadget is completely automated, allowing simple and smooth combination your current manufacturing bodies. The robot is offered with an easy-to-use display which allows drivers towards strategy the robot towards practically give glues in any type of style or even form.


This 3-axis dispensing robot automatic epoxy resin glue dispensing Silicone Epoxy Resin Adhesive Dispenser robots through Minder-Hightech is created creating use of products that are top quality elements. The robot is created towards endure the most difficult commercial environments creating specific it does perfectly in any type of atmosphere. The robot can be designed towards be low-maintenance, needing very little upkeep maintenance, which conserves opportunity and cash in the long term.
